No.
|
|
Related technical parameters
|
|
1
|
Effective Milling length
|
4000
|
6000
|
9000
|
12000
|
14000
|
16000
|
18000
|
|
2
|
Processing of plate thickness
|
6-50（Can also be customized according to user）
|
|
3
|
Milling angle
|
0-45
|
|
4
|
Fast forward and rewind speed
|
0-1100（Variable frequency stepless）
|
|
5
|
Milling speed
|
100-700（Decided by the sheet material milling speed）
|
|
6
|
Milling level maximum stroke
|
≥100mm
|
|
7
|
Vertical Milling maximum stroke
|
≥120mm
|
|
8
|
Surface roughness
|
Ra3.2-6.3
|
|
9
|
Milling spindle speed
|
580(Milling machine for milling） can also configure other non-standard or standard milling
|
|
10
|
Hydraulic binder cylinders (only)
|
5
|
7
|
11
|
15
|
17
|
20
|
23
|
|
11
|
Prop rack only a few (only)
|
5
|
7
|
10
|
12
|
14
|
16
|
18
|
|
12
|
Binder height from the ground station
|
850
|
|
13
|
Feed motor power
|
1.5 Frequency Control (two-stage cycloid reducer)
|
|
14
|
Milling Motor Power
|
5.5 (can also be configured according to user requirements)
|
|
15
|
Hydraulic pump motor power
|
5.5
|
